VZ 18 series trailers are unbraked trailers with a total weight of 750 kg or braked trailers with a total weight up to 1000 kg, 350 mm high side boards and completely welded chassis frame.
Loading platform dimensions 1760x1095x350 mm.
Tubular or V-drawbar design, 350 mm plywood or aluminium side boards, 13" wheels, 7-pole electrical installation and plug for unbraked trailers and 13-pole electrical installation and plug for braked trailers, 15 mm thick waterproof plywood flooring, solid welded chassis frame with reinforcements.
Braked versions of the VZ 18 series trailers are equipped, in a standard design, with a jockey wheel with a holder, wheel scotch blocks and AGADOS rear SMART LED lamps.
The tubular drawbar enables easier access to the area under the loading platform of the trailer.
VARIANTS, MODIFICATIONS, ACCESSORIES
VZ 18 series trailers can be equipped with useful accessories or various modifications can be selected
■ jockey wheel with holder
■ supporting legs complete with holder
■ side board extension
■ coupling lock
■ lockable plastic cover
■ aluminium cover
■ flat canvas or canvas with construction
■ wheel scotch blocks
■ spare wheel
■ spare wheel holder
■ hand jack for the tilting design
■ reinforced coupling for unbraked versions
■ reinforced axle for unbraked versions
■ axle dampers (shock absorbers)
■ tilting design of trailer body up to the total weight of 1000 kg
■ opening front board
■ railing
■ V-drawbar instead of tubular drawbar for unbraked versions
■ 13-pole electrical installation and plug for unbraked versions
■ AGADOS LED lighting (for unbraked trailers)
■ side board extension 500 mm
